With the accelerated pace of urban life and the rapid development of Internet o2o, more and more people choose takeout to solve the catering problem in many occasions. At present, the takeout way is to directly pack the fast food in the disposable lunch box, and then the takeout brother gives the disposable lunch box containing the food to the user. Because the takeout brother delivers a lot of food at one time, his travel mode is mostly electric vehicles, and the packaged takeout lunch boxes are put in the incubator at the end of the electric vehicle, which makes the road bumpy, Moreover, improper placement of the lunch box can easily cause the soup leakage in the lunch box, pollute the incubator and reduce the user experience.

為解決現有外賣塑料飯盒的湯汁外漏問題，提供一種防漏外賣塑料飯盒，結構簡單密封效果好，緩解湯汁留出盒外的情況。

In order to solve the problem of soup leakage of the existing takeaway plastic lunch box, a leakproof takeaway plastic lunch box is provided, which has simple structure, good sealing effect and alleviates the situation of soup leaving out of the box.


為解決上述問題采用如下的技術方案：

In order to solve the above problems, the following technical solutions are adopted:

一種防漏外賣塑料飯盒，包括盒體與其表面相配合的盒蓋，所述盒體由四個側邊與一個底面一體成型，所述側邊為具有一定厚度的雙層結構，每個所述側邊內部上方均設有輸水通道和多個滲漏孔，每個所述側邊的每個所述滲漏孔均與所述輸水通道連通，所述盒體還包括兩個集水空腔，兩個所述集水空腔設置于所述盒體的對角線的兩端，所述輸水通道一端與所述集水空腔連通。

The utility model relates to a leakproof takeout plastic lunch box, which comprises a box cover matched with the box body and its surface. The box body is integrally formed by four sides and a bottom surface, the side is a double-layer structure with a certain thickness, the inner upper part of each side is provided with a water conveyance channel and a plurality of leakage holes, and each leakage hole of each side is connected with the water conveyance channel, The box body also comprises two water collecting cavities, the two water collecting cavities are arranged at both ends of the diagonal line of the box body, and one end of the water conveyance channel is connected with the water collecting cavity.

盒蓋包括蓋沿、盒蓋斜坡、盒蓋底面以及盒蓋側邊。

The box cover comprises a cover edge, a box cover slope, a box cover bottom surface and a box cover side.

輸水通道傾斜設置，其較低端與所述集水空腔連通。

The water conveyance channel is obliquely arranged, and the lower end of the water conveyance channel is communicated with the water collecting cavity.

進一步的，蓋沿厚度與所述側邊上端面厚度相同，所述盒蓋斜坡可與所述盒體內部四個側邊內壁貼合。

Furthermore, the thickness of the cover along the edge is the same as that of the upper end face of the side, and the slope of the box cover can fit with the inner walls of the four sides inside the box body.

防漏外賣塑料飯盒采用食品 級PP材料。

Food grade PP material is used for leak proof plastic lunch box.

的有益效果在于：

The beneficial effects are as follows

(1)提供一種防漏外賣塑料飯盒，蓋沿厚度與所述側邊上端面厚度相同，所述盒蓋斜坡可與所述盒體內部四個側邊內壁貼合，增加盒蓋與盒體直接的貼合程度，從而降低湯汁外露的可能。

(1) A leakproof takeaway plastic lunch box is provided. The thickness of the cover along the edge is the same as the thickness of the upper end face of the side. The slope of the cover can fit with the inner walls of the four sides inside the box body to increase the direct fit degree between the cover and the box body, so as to reduce the possibility of soup exposure.

(2)若有湯汁進入盒蓋斜坡與盒體內壁之間，可通過滲漏孔進入輸水通道，會流至集水空腔中，進一步緩解湯汁留出盒外的情況。

(2) If the soup enters between the slope of the box cover and the inner wall of the box, it can enter the water conveyance channel through the leakage hole and flow into the water collecting cavity to further alleviate the situation of the soup leaving outside the box.
